Hayward® TW Series 3-Way PVC True Union Valves

Valves come standard with a two-port "TW" ball allowing for three flow configurations within 180° of rotation. With the bottom port as the inlet, the flow can be directed out the left port, out the right port, or shut off. An optional "TP" ball, used with either manual or actuated valves, allows the flow to go through all ports at the same time or flow shutoff. Also available in CPVC or with EPDM seals. Contact us for pricing on CPVC, actuation, and ball options.

  • PVC
  • FPM O-rings
  • PTFE seats
  • The integrated molded bottom port
  • Position indicator
  • Double O-ring stem seal
  • Pressure rating: 150 psi @ 70°F non-shock
  • Temperature rating: 140°F
Item # Description Catalog Pg. Price Add to Cart
1/2" Threaded/Socket TW Series 3-Way PVC True Union Valve
Item 19306
163.39/Each
Save 5% when you buy 2+
Save 10% when you buy 4+
Save 15% when you buy 12+
P-554
163.39/Each
3/4" Threaded/Socket TW Series 3-Way PVC True Union Valve
Item 19307
193.72/Each
Save 5% when you buy 2+
Save 10% when you buy 4+
Save 15% when you buy 12+
P-554
193.72/Each
1" Threaded/Socket TW Series 3-Way PVC True Union Valve
Item 19308
235.39/Each
Save 5% when you buy 2+
Save 10% when you buy 4+
Save 15% when you buy 12+
P-554
235.39/Each
1-1/2" Threaded/Socket TW Series 3-Way PVC True Union Valve
Item 19309
331.13/Each
Save 5% when you buy 2+
Save 10% when you buy 4+
Save 15% when you buy 12+
P-554
331.13/Each
2" Threaded/Socket TW Series 3-Way PVC True Union Valve
Item 19310
420.87/Each
Save 5% when you buy 2+
Save 10% when you buy 4+
Save 15% when you buy 12+
P-554
420.87/Each
3" TW Series 3 -Way Valve, Threaded True Union
Item 19317
1340.53/Each
Save 5% when you buy 2+
Save 10% when you buy 4+
Save 15% when you buy 12+
P-554
1340.53/Each
3" Socket TW Series 3-Way PVC True Union Valve
Item 19316
1340.53/Each
Save 5% when you buy 2+
Save 10% when you buy 4+
Save 15% when you buy 12+
P-554
1340.53/Each
4" Threaded TW Series 3-Way PVC True Union Valve
Item 19319
2318.95/Each
Save 5% when you buy 2+
Save 10% when you buy 4+
Save 15% when you buy 12+
P-554
2318.95/Each
4" Socket TW Series 3-Way PVC True Union Valve
Item 19318
2318.95/Each
Save 5% when you buy 2+
Save 10% when you buy 4+
Save 15% when you buy 12+
P-554
2318.95/Each
